Transient and Permanent Surge Protector 2P 63A

The Procoel ST-2P63 surge protector is a combined device for single-phase electrical installations that protects against permanent and transient overvoltages and incorporates a 63 A Main Circuit Breaker (IGA). Its design integrates into a single unit protection against prolonged increases in mains voltage, transient surge discharge, and magnetothermal protection, simplifying installation in the electrical panel.

The ST-2P63 reference operates at 240 V AC, features a C-curve IGA with a breaking capacity of 6 kA and Class II transient overvoltage protection. Its protection level Up is ≤1.5 kV, with a maximum discharge current Imax of 12.5 kA on an 8/20 µs waveform and a nominal discharge current In of 6 kA. It is installed on a 35 mm DIN rail and occupies 3 modules.

Combined protection against permanent and transient overvoltages

The Procoel ST-2P63 combines two protection systems against voltage anomalies that can affect equipment connected to an electrical installation.

• Permanent overvoltages: continuously monitors the mains voltage and trips the IGA when it detects a sustained rise above the set threshold.
• Transient overvoltages: limits very short voltage spikes that may be caused by atmospheric phenomena or switching operations in the electrical network.

This combination allows electrical and electronic loads connected downstream to be protected by a single device against different types of overvoltage.

Integrated 63 A IGA

The ST-2P63 reference incorporates a 63 A Main Circuit Breaker, eliminating the need to externally pair the surge module with a separate IGA.

The integrated thermal-magnetic breaker features a C tripping curve and a breaking capacity of 6 kA. In this way, in addition to acting when the module detects a permanent overvoltage, the IGA provides the corresponding thermal-magnetic protection against overloads and short circuits within its rated characteristics.

Class II transient overvoltage protection

For transient overvoltages, the ST-2P63 incorporates a Class II protector intended for distribution boards in low-voltage installations.

Its main transient protection parameters are:

• Maximum discharge current Imax: 12.5 kA with 8/20 µs waveform.
• Nominal discharge current In: 6 kA.
• Protection level Up: ≤1.5 kV.
• Class: II.

In the event of a transient overvoltage, the module diverts and limits the disturbance to reduce the voltage reaching the electrical equipment installed downstream.

Protection against permanent overvoltages

The unit continuously measures the installation voltage. When it detects a rise above the expected limit, it acts on the integrated IGA and disconnects the installation supply.

The currently linked technical datasheet from the manufacturer specifies a trip voltage above 265 V AC ±2%. The operating time depends on the magnitude of the overvoltage in accordance with the requirements of UNE-EN 50550.

Once normal voltage values are restored, the unit must be manually reset to supply the installation again.

Visual indicator of the protector status

The ST-2P63 includes an indicator window that allows the status of the surge protection module to be checked.

• Slow green flashing: device correctly connected and operational.
• Fast green flashing: indicates a wiring error between phase and neutral.
• Steady green after a transient overvoltage: the protector remains operational.
• Red indicator: the transient protection module has been damaged and must be replaced.

This indication makes it easy to visually inspect the device status during electrical panel maintenance operations.

For single-phase installations with phase and neutral

The Procoel ST-2P63 is specifically designed for single-phase installations. The phase must be connected to terminal L and the neutral to terminal N, strictly following the wiring diagram indicated by the manufacturer.

The manufacturer expressly states that the unit must not be installed on lines without neutral or in installations that do not have a protective PE earth connection.

Earth grounding is essential

For transient overvoltage protection to function correctly, the installation must have an adequate grounding system.

A properly executed PE connection allows the energy diverted by the protector during a transient overvoltage to be conducted to earth. The installation must be carried out in compliance with the conductor cross-sections, lengths and conditions established by the applicable electrical regulations.

Compact 3-module DIN format

The ST-2P63 is designed for mounting on a 35 mm DIN rail and occupies 3 modules of 18 mm. Its approximate dimensions are 54 x 90 x 71 mm, making it easy to integrate the combined protector into residential, commercial and tertiary electrical panels.

By integrating the IGA and surge protection in a single unit, it reduces the number of separate devices required in the panel.

Terminals for conductors up to 25 mm²

The device terminals accept a maximum conductor cross-section of 25 mm² according to the manufacturer’s datasheet. The actual cross-section used must be sized according to the expected current, the installation system and the applicable regulatory requirements.

IP20 protection rating

The unit has an IP20 protection rating and is designed to be installed inside an electrical panel or enclosure that provides the necessary protection against contact, moisture and environmental conditions.

The manufacturer specifies operating environmental conditions of approximately -20 to +70 °C and up to 80% relative humidity.

Applications of the Procoel ST-2P63 protector

The ST-2P63 combined protector is intended for single-phase electrical panels where thermal-magnetic protection and protection against permanent and transient overvoltages are to be integrated.

• Residential electrical panels.
• Homeowners’ associations.
• Retail premises.
• Offices.
• Tertiary installations.
• Small workshops.
• Installations with appliances and sensitive electronics.
• Single-phase panels requiring a 63 A IGA.

Technical characteristics of the Procoel ST-2P63

• Brand: Procoel / Hyundai Electric.
• Reference: ST-2P63.
• Range: HYPRO-ST.
• Type: combined permanent and transient overvoltage protector with IGA.
• Application: single-phase installation.
• Number of poles: 2.
• Rated current: 63 A.
• Integrated IGA: yes.
• IGA curve: C.
• IGA breaking capacity: 6 kA.
• Rated operating voltage: 240 V AC.
• Frequency: 50-60 Hz.
• Permanent protection: yes.
• Permanent trip voltage: >265 V AC ±2% according to current datasheet.
• Reset after permanent overvoltage: manual.
• Transient protection: yes.
• Transient protection class: Class II.
• Nominal discharge current In: 6 kA.
• Maximum discharge current Imax: 12.5 kA, 8/20 µs waveform.
• Protection level Up: ≤1.5 kV.
• Status indicator: yes.
• Maximum terminal conductor size: 25 mm².
• Mounting: 35 mm DIN rail.
• DIN modules: 3.
• Approximate dimensions: 54 x 90 x 71 mm.
• Protection rating: IP20.
• Ambient temperature: -20 to +70 °C.
• Maximum indicated relative humidity: 80%.
• Indicated standards: UNE-EN 60898, EN 50550 and IEC/EN 61643-11.
• Neutral required: yes.
• PE earth connection required: yes.

Comprehensive protection for 63 A single-phase panels

The Procoel ST-2P63 combines a 63 A IGA and two levels of protection against voltage anomalies in just 3 DIN modules. Permanent protection disconnects the installation in the event of a sustained voltage rise, while the Class II limiter acts against short-duration transient overvoltages.

Its protection level Up ≤1.5 kV, maximum discharge current of 12.5 kA and integrated C-curve IGA provide a compact solution for protecting single-phase panels in homes, shops and other low-voltage installations.

Important: the manufacturer requires the phase L and neutral N connection to be respected and specifies that the ST-2P63 must not be installed on lines without neutral or without PE earth connection. Installation must be carried out by a qualified professional.
